Selling like hotcakes LED screen shows Single Phase Relay Controlled SRFII-4000D Automatic AC Voltage Regulator
Description
|
Model
|
SRFII-4000
|
SRFII-6000D
|
SRFII-9000D
|
SRFII-12000D
|
||||||
|
Nominal Power
|
4000VA
|
6000VA
|
9000VA
|
12000VA
|
||||||
|
Power Factor
|
0.6-1.0
|
|||||||||
|
Input
|
||||||||||
|
Operating Voltage Range
|
A: 70~285V、B: 90~285V、C: 125~285V
|
|||||||||
|
Regulation Voltage Range
|
A: 80~260V、B: 100~260V、C: 140~260V
|
|||||||||
|
Frequency
|
50HZ
|
|||||||||
|
Connection Type
|
Input terminal block
|
|||||||||
|
Output
|
||||||||||
|
Operating Voltage
|
180~255V
|
|||||||||
|
High Cut Voltage
|
255V
|
|||||||||
|
Low Cut Voltage
|
180V
|
|||||||||
|
Safety Cycle
|
8 Seconds / 180 Seconds (Optional)
|
|||||||||
|
Frequency
|
50HZ
|
|||||||||
|
Connection Type
|
Output terminal block
|
|||||||||
|
Regulation
|
||||||||||
|
Regulation %
|
8%
|
|||||||||
|
Number of Taps
|
7
|
|||||||||
|
Transformer Type
|
Toroidal auto transformer
|
|||||||||
|
Regulation Type
|
Relay type
|
|||||||||
|
Indicators
|
||||||||||
|
LED digital display
|
Input voltage
Output voltage Delay time Load usage Normal working Temperature of transformer Error code |
|||||||||
|
Protection
|
||||||||||
|
Over Temperature
|
Auto Shutdown at 120 ℃
|
|||||||||
|
Short Circuit
|
Auto Shutdown
|
|||||||||
|
Overload
|
Auto Shutdown
|
|||||||||
|
Over / Under Voltage
|
Auto Shutdown
|
|||||||||
|
Packaging information
|
||||||||||
|
Model
|
Unit(PCS)
|
Device Size(MM)
|
Package Size(MM)
|
G. W. (KGS)
|
||||||
|
SRWII-4000-L
|
1
|
350*245*210
|
430*325*280
|
12.52
|
||||||
|
SRWII-6000-L
|
1
|
350*245*210
|
430*325*280
|
13.62
|
||||||
|
SRWII-9000-L
|
1
|
350*245*210
|
505*325*280
|
19.54
|
||||||
|
SRWII-12000-L
|
1
|
430*245*210
|
505*325*280
|
21.42
|
||||||
Q 1. What's the payment term
A. We accept TT, 30% deposit and 70% balance against copy of BL.
Q 2. How's the delivery time
A. usually it will take about 10-25 days for production. For sample usually in 1 week.
Q 3. Tell me the standard of package
A. For the small capacity, color box as inner package and carton as delivery package
For big capacity, use strong wooden case for protection.
Q 4. What kind of material of transformer
A. For servo type stabilizer, we have two types, one 100% copper and the other is copper with aluminum. It depends on your requirement. In fact, those two have no difference if normal work well. Only except the long-life. Copper is better and also higher price. For relay type stabilizer, we use toroid coils, the material is aluminum. comparing with square coils, Toroid coils with high efficiency.
Q 5. Could you offer Form A or C/O
A. It totally not a problem. We can prepare relative documents to forging affairs office or other office to apply for this certificate.
Q 6. Would you accept to use our logo
A. Our logo is HEYA. If your order has good quantity, it absolutely no problem to do OEM
But you use our logo HEYA will be high appreciated.
Q 7. We want to know month capacity
A. It depends on which model. For example, for relay type small capacity, month capacity can reach near 10000pcs and big capacity near 2000pcs.
Q 8. Where is your market
A. Our products are popular in North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western European so on. Some of them are our regular customers and some of them are developing. We hope you can join us and make mutual benefit from our cooperation.
Q 9. What kind of certificate you have
A. Our company already obtained ISO9001, BV, EAC, SONCAP, CE, PCT, SGS, design and technical patents certificates.
HEYA
Introducing the Single-Phase Relay Controlled SRFII-4000D Automatic AC Voltage Regulator. This is selling like hotcakes and it's not hard to see why. With its high-quality LED screen display this voltage regulator is perfect for regulating AC voltage with precision and accuracy.
Features a sleek and compact design that makes it easy to use and store. Built with durability in mind so you can expect it to withstand wear and tear from daily use. Whether you're a professional electrician or just someone who wants to ensure that their electronic devices have a constant power supply this voltage regulator is the perfect choice.
With LED screen display that shows the voltage of the input and output in real-time. This HEYA means you can monitor the voltage of your electronics without having to guess or estimate. This feature is especially useful for electronics that require precise voltage such as medical equipment laboratory machines and more.
Equipped with a single-phase relay control system that makes it easy to regulate voltage. Built-in protection system that protects against overvoltage under voltage and overload. This added protection ensures that your electronics are always safe from damage caused by voltage fluctuations.
Easy to install and use. It comes with clear and concise instructions that make it easy for anyone to set up and operate. Perfect for use in homes offices laboratories hospitals and more.
Don't miss out on the opportunity to benefit from this amazing product today.
