90-270V Input Range 220V 15KVA Single Phase Automatic AC Voltage Regulator Stabilizer AVR
Description
The HEYA 90-270V Input Range 220V 15KVA Single Phase Automatic AC Voltage Regulator Stabilizer AVR will be the solution perfect your voltage regulation requirements. Whether you are working together with energy changes as a result of unstable electric grids or attempting to protect your painful and sensitive electronic equipment this voltage regulator stabilizer will be the option way better. Featuring its compact design and installation straightforward you'll be all set very quickly. This regulator stabilizer is wonderful for preserving your products sound and safe from any charged energy surges or changes. It is created using the technology latest to hold it working flawlessly for a time long the long term. Its 90-270V input range will be the perfect fit for some electric systems supplying accuracy unparalleled. The HEYA regulator stabilizer could be an operational system automated what this means is it would likely sense the voltage changes and adjust the production appropriately. This helps to ensure your products or services are protected from under-voltage over-voltage and some other energy problems that may arise. The regulator was created be effective quietly there won't be any hums which are irritating buzzes whenever you are utilizing it. The regulator is just a stage solitary and contains now a capacity for 15KVA meaning that its with the capacity of supplying just as much as 220 volts of production voltage with great precision and accuracy. The machine can also be compact in design this means it may nearly easily fit any area in. Its little size means it's not likely to occupy area a whole lot nevertheless it is similarly essential to say it doesn't compromise on performance. The HEYA regulator stabilizer normally quite simple to set up. It comes down having a manual that guides you through the installation procedure as well as procedure entire not simply take you a complete lot significantly more than 30-45 moments. As soon as set up the regulator shall care for your voltage legislation requires offering you satisfaction
|
Model
|
SRV-15000-PLUS
|
SRV-20000-PLUS
|
||||||||
|
Nominal Power
|
15000VA
|
20000VA
|
||||||||
|
Power Factor
|
0.6-1.0
|
|||||||||
|
Input
|
||||||||||
|
Operating Voltage Range
|
A: 40~290V、B: 55~290V、C: 85~290V、D: 125~285V
|
|||||||||
|
Regulation Voltage Range
|
A: 45~280V、B: 60~280V、C: 90~280V、D: 140~270V
|
|||||||||
|
Frequency
|
50HZ
|
|||||||||
|
Connection Type
|
Input terminal block
|
|||||||||
|
Output
|
||||||||||
|
Operating Voltage
|
180~255V
|
|||||||||
|
High Cut Voltage
|
255V
|
|||||||||
|
Low Cut Voltage
|
180V
|
|||||||||
|
Safety Cycle
|
3 Seconds / 180 Seconds Optional
|
|||||||||
|
Frequency
|
50HZ
|
|||||||||
|
Connection Type
|
Input terminal block
|
|||||||||
|
Regulation
|
||||||||||
|
Regulation %
|
8%
|
|||||||||
|
Number of Taps
|
5
|
|||||||||
|
Transformer Type
|
Toroidal auto transformer
|
|||||||||
|
Regulation Type
|
Relay type
|
|||||||||
|
Indicators
|
||||||||||
|
LED digital display
|
Input voltage 、Output voltage 、Delay time
|
|||||||||
|
Protection
|
||||||||||
|
Over Temperature
|
Auto Shutdown at 120 ℃
|
|||||||||
|
Short Circuit
|
Auto Shutdown
|
|||||||||
|
Overload
|
Auto Shutdown
|
|||||||||
|
Over / Under Voltage
|
Auto Shutdown
|
|||||||||
|
Packaging information
|
||||||||||
|
Model
|
Unit PCS
|
Device Size MM
|
Package Size MM
|
G. W. KGS
|
||||||
|
SRV-15000-D
|
1
|
310*270*560
|
410*360*650
|
30
|
||||||
|
SRV-20000-D
|
1
|
360*340*620
|
450*430*725
|
37
|
||||||
Mob/WeChat/Whatsapp: +8613736244360
Skype: live: zyz0219
A. We accept TT, 30% deposit and 70% balance against copy of BL
Q 2. How's the delivery time?A. usually it will take about 10-25 days for production. For sample usually in 1 week.
Q 3. Tell me the standard of package?
A. For the small capacity, color box as inner package and carton as delivery package.
For big capacity, use strong wooden case for protection.
Q 4. What kind of material of transformer?
A. For servo type stabilizer, we have two types, one 100% copper and the other is copper with aluminum. It depends on your requirement. In fact, those two have no difference if normal work well. Only except the long life. Copper is better and also higher price. For relay type stabilizer, we use toroid coils, the material is aluminum comparing with square coils, toroid coils with high efficiency.
Q 5. Could you offer Form A or C/O?
A. It totally not a problem. We can prepare relative documents to forgive affairs office or other office to apply for this certificate.
Q 6. Would you accept to use our logo?
A. Our logo is HEYA. If your order has good quantity, it absolute no problem to do OEM.
But you use our logo HEYA will be high appreciated.
Q 7. We want to know month capacity.
A. It depends on which model. For example for relay type small capacity, month capacity can reach near 10000pcs and big capacity near 2000pcs.
Q 8. Where is your market?
Q 9. What kind of certificate you have?
A. Our company already obtained ISO9001, BV, EAC, SONCAP, CE, PCT, SGS, design and technical patents certificates
